Mesh and palisade security fencing, railings, and automated cantilever, swing and pedestrian gates. Every bay set out on the ground it stands on, the gates drawn with their operators, safety devices and foundations.
What comes back, stage by stage. Take the stages you need.
| Layout | Fence runs set out bay by bay on the ground, stepped or raked to the levels, posts and footings scheduled. |
| Type GAs | An elevation and section for each fence type, with the mesh, clamp bars, pales and fixings. |
| Gates | Gate GAs with the leaf, track, operator, safety edges and photocells, foundations and ducts. |
| Order | Panels, posts, fixings and gate kit counted from the model. |
Made-up jobs, drawn the way a real one is: the model, the renders and the sheets that come out of it. Click a sheet to read it whole.
PDF, 2 sheets, 1 MB. Ask for the full pack.
AL05Sample project
Mesh and palisade fencing with a 10 m cantilever gate
A depot perimeter on sloping ground: 358 mesh stepped on its grid, W-pale palisade, a 10 m cantilever gate, a 6 m swing pair and pedestrian gates, with their operators, safety devices and foundations.
Open the sheet
Open the sheet
AQ15Sample project
Podium railings on piers, with gates
Bar railings between brick piers round the podium garden, the panels set out bay by bay between the piers.
Fixed before any work starts, on your drawings. No VAT charged.
| Pack | From | Turnaround |
|---|---|---|
| Type GAPer fence type: elevation, section, fixings | £295 | 2 days |
| Gate GA + fabricationPer gate: GA, assemblies, plates, foundations | £595 | 3 days |
| Layout and set-outEvery bay on the ground, posts and footings | £250 | next day |
Your engineer designs the steel; the drawings follow that design.
Send the drawings and get a fixed price back within four hours.
Not ready to send drawings? Ask for the full sample pack for your type of work, or a call back, with the form.
