Services/Facades, SFS and windows
Metsec SFS infill between the slabs, rainscreen rails and brick slip, windows, doors and Juliets. Every run laid out from the members themselves, every opening scheduled, the interfaces detailed.
What comes back, stage by stage. Take the stages you need.
| SFS layouts | Every run: studs, jambs, cripples, tracks, joints and set-out chains, from the members themselves. |
| Details | Slab edge, head, jamb and cill, the deflection head and the bracket into the SFS. |
| Windows and doors | Opening and door schedules, elevations by type, installation and surround details. |
| Take-off | Members, tracks and fixings counted, cut lists by stud size. |
Made-up jobs, drawn the way a real one is: the model, the renders and the sheets that come out of it. Click a sheet to read it whole.
PDF, 3 sheets, 1 MB. Ask for the full pack.
KP10Sample project
Metsec SFS infill to a 12-storey residential block
47 runs of SFS between the slabs, studs sized from the load tables, openings from the rooms behind, brick tile and cassettes, windows and 88 Juliets, drawn as the SFS designer’s pack and an approval set.
Open the sheet
Open the sheetAQ15Sample project
SFS and windows going in behind sheeted scaffold
On block C the Metsec SFS, brick slip and SAS aluminium windows go in behind the scaffold, every opening scheduled.
Fixed before any work starts, on your drawings. No VAT charged.
| Pack | From | Turnaround |
|---|---|---|
| Approval setPlans, elevations, build-ups, schedules | £295 | 2 days |
| SFS layout packEvery run, details, take-off and cut lists | quoted per job |
Your engineer designs the steel; the drawings follow that design.
Send the drawings and get a fixed price back within four hours.
Not ready to send drawings? Ask for the full sample pack for your type of work, or a call back, with the form.
